Plan 65867
Specifications
| Total Living Area: | 1848 sq ft |
| Main Living Area: | 1848 sq ft |
| Bonus Area: | 349 sq ft |
| Unfinished Basement Area: | 2013 sq ft |
| Garage Area: | 792 sq ft |
| Garage Type: | Attached |
| Garage Bays: | 2 |
| Foundation Types: | Basement – * $395.00 Total Living Area may increase with Basement Foundation option. Crawlspace – * $195.00 Slab Walkout Basement – * $495.00 Total Living Area may increase with Basement Foundation option. |
| Exterior Walls: | 2×4 2×6 – * $345.00 |
| House Width: | 78’9 |
| House Depth: | 71’5 |
| Number of Stories: | 1 |
| Bedrooms: | 3 |
| Full Baths: | 2 |
| Max Ridge Height: | 30′ from Front Door Floor Level |
| Primary Roof Pitch: | 12:12 |
| Roof Load: | 20 psf |
| Roof Framing: | Stick |
| Porch: | 448 sq ft |
| Deck: | 281 sq ft |
| Formal Dining Room: | Yes |
| FirePlace: | Yes |
| 1st Floor Master: | Yes |
| Main Ceiling Height: | 10′ |
| Upper Ceiling Height: | 9′ |
* May require additional drawing time.
Special Features:
- Bonus Room
- Front Porch
- Lania
- Outdoor Fireplace
- Outdoor Kitchen
- Pantry
- Rear Porch
- Storage Space
- Workshop
What’s Included
Our working drawings include the following..
We use AutoCAD to produce our working drawings. This allows us to be 100% accurate on our dimensions as well as coordinate all drawings with the highest level of precision. Below are examples of what comes in each working drawing set…
Floor Plans – For each level we include… a 1/4″=1′-0″ scale floor plan indicating frame walls and masonry with dimensions, notes, door and window sizes, room names and floor finishes, cabinet, shelving, fixture locations and notes, ceiling conditions, electrical/lighting fixtures and switches.
Exterior Elevations – We include… Front Elevation at 1/4″=1′-0″, side and rear elevations at 1/8″=1′-0″, plate heights, roof overhangs, material/surface notes, window heights, roof pitches, material hatching for clarity, floor to floor dimensions and any other detail we feel is necessary to explain the construction.
Cabinets/Building Sections- Cabinet elevations at 3/8″=1′-0″, showing cabinets, appliance locations, plumbing fixtures, shelving, counter/backsplash surface, cabinet material and finish, niche details and any other special situation that cannot be understood from the plan view. Building Sections are included only when there is no other way to indicate the spatial characteristics of the home. This information is quite often indicated well enough on the elevations and plans.
Foundation Plans – We offer a choice of three types of foundations, full basement, crawlspace, and slab foundations. Each comes fully dimensioned, and noted indicating wall composition and thickness, construction detail references to our detail page, beam, pier and column locations and sizes, stair locations for basements, reinforcing steel sizes and step downs in monolithic slabs and ventilation grilles for crawlspaces.
Framing Plans – For each level we include… a 1/8″=1′-0″ scale plan indicating rafter, ceiling and floor joists locations, sizes and spacing as well as lumber grade specified, additional bracing and blocking.
Details – For each foundation type we include… 3/4″=1′-0″ scale details indicating material composition, size and critical dimensions for construction of the primary foundation.
Plan Pricing from $1,095.00
Plan Pricing
- PDF File: $1,095.00
- 5 Sets: $1,295.00
- 5 Sets plus PDF File: $1,395.00
- CAD File: $2,095.00
Single Build License issued on CAD File orders. - CAD File Unlimited Build: $2,790.00
Unlimited Build License issued on CAD File Unlimited Build orders. - Right Reading Reverse: $245.00
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days. - Additional Sets: $60.00
Additional Notes
Bathroom 2 10 x 6 Utility 5.4 x 6.8
Plan Options:
- 3-Car Garage Option: $195.00
Available Foundation Types:
- Basement : $395.00
May require additional drawing time, please call to confirm before ordering.
Total Living Area may increase with Basement Foundation option. - Crawlspace : $195.00
May require additional drawing time, please call to confirm before ordering. - Slab : No Additional Fee
- Walkout Basement : $495.00
May require additional drawing time, please call to confirm before ordering.
Total Living Area may increase with Basement Foundation option.
Available Exterior Wall Types:
- 2×4: No Additional Fee
- 2×6: $345.00
(Please call for drawing time.)
Prices subject to approval prior to fulfillment.
